Canon imagePROGRAF TX-3000 36" Large-Format Inkjet Printer‎

Overview

The 36-inch large-format inkjet printer that couples class-leading quality with supreme output speeds. The imagePROGRAF TX-3000 benefits from innovative features, low-cost operation, simplified upkeep and Canon’s trademark reliability.

Fast large-format printing
An advanced 1.07-inch print head is allied with continuous printing capability, helping this 36-inch model to return excellent productivity and workflow efficiency.

Astounding print accuracy
The high surface tension of the LUCIA TD ink achieves unparalleled fine detail precision, even on economical uncoated stock, and ensures steadfast weather resilience.

Seamless, swift management
The compact imagePROGRAF TX-3000 integrates easily into small offices, and offers simple operation with its touchscreen display, dual roll feeding and easy loading.

Secure and steadfast
Full control over user privileges and device access, as well as disk encryption, safe disk erasure and data transmission encryption, result in unparalleled security.

Superb software suite
With an Autodesk-optimised AutoCAD driver and a media configuration tool to create the perfect printing environment, the TX-3000 is built for the most exacting tasks.

Specification

Printer Type

5 Colour - 36"/914.4mm

Print Technology

Canon Bubblejet on Demand 6 colours integrated type (6 chips per print head x 1 print head)
Number of Nozzles

Total: 15,360 MBK: 5,120 nozzles
C, M, Y, BK: 2,560 nozzles each
Print Resolution

2,400 x 1,200 dpi
Nozzle Pitch

1,200 x 2 includes Non-firing nozzle detection and compensation system
Line Accuracy

±0.1 % or less
Ink Droplet Size

5 Picolitre per colour
Ink Capacity

Bundled Starter Ink: 330ml (MBK)/160ml (BK,C,M,Y)
Sales Ink: 160ml/330ml/700ml
Ink Type

Pigment ink: 5 colour　MBK/BK/C/M/Y
OS Compatability

Microsoft Windows 32 Bit: 7, 8.1, 10, Server 2008, 64 Bit: 7, 8.1, 10, Server 2008/ R2, Server 2012/R2
Apple Macintosh: OSX 10.10.5 ~ 10.11, MacOS 10.12
Printer Languages

HP-GL/2, HP RTL, PDF, JPEG - for details check specifications
Standard Interfaces

CHANGE:
USB B Port:
Type: Built in (Hi-Speed USB)
Mode: Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk transfer

Connector Port: Series B (4 pins)
USB A Port: USB Memory (Direct Print）
Standard:
IEEE 802.3 10base-T
IEEE 802.3u 100base-TX/Auto-Negotiation
IEEE 802.3ab 1000base-T/Auto-Negotiation
IEEE 802.3x Full Duplex

Protocol:
SNMP (Canon-MIB, HTTP, TCP/IP (IPv4/IPv6), ftp
Wireless LAN:
Standard:
IEEE802.11n/IEEE802.11g/IEEE802.11b

Security:
WEP (64/128bit)
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)

Memory
Standard Memory

128GB (Physical memory 2GB)
Expansion slot

No
Printing Speed

CAD Drawing
Plain Paper (A0 Roll)
0:37 (Fast Economy Mode)
0:40 (Fast)
1:10 (Standard)

Poster
Plain Paper (A0 Roll)
0:42 (Fast Economy mode)
0:42 (Fast)
1:26 (Standard)
Heavy coated Paper (A0 Roll)
1:43 (Fast)
2:37 (Standard)
HARD DISK

500GB (Encrypted)
Paper Handling
Media Width

Roll paper: 203.2mm - 917mm
Cut sheet: 203.2mm - 917mm
Media Thickness

0.07 - 0.8mm

Minimum Printable Length

203.2mm
Maximum Printable Length

Roll paper: 18m (varies according to the OS and application)
Cut sheet: 1.6m
Maximum Media Roll Diameter

170mm

Paper Feed Method

Roll Paper: Front loading, front output
Cut Sheet: Front loading, front output
(Manual feed using media locking lever)
Borderless Printing Width (Roll Only)

[Recommend] 515mm(JIS B2), 728mm(JIS B1), 594mm(ISO A1), 841mm(ISO A0), 10", 14", 17", 24", 36"
[Printable] 257mm(JIS B4), 297mm(ISO A3), 329mm(ISO A3+), 420mm(ISO A2), 8", 12", 16, 20", 30", 300mm, 500mm, 600mm, 800mm

Maximum Numbers of delivered prints Multi-position Basket

Standard Position : 1 sheet (any image)
Flat Position : 20 sheets (A2 landscape, any image, plain paper/coated paper)

Maximum Numbers of delivered prints Stacker

Basket Position : 1 sheet (any image)
Folding Position : 100 sheets (A0/A1 portrait, CAD drawing, plain paper)
Stacking Position : 100 sheets (A1/A2 landscape, CAD drawing, plain paper)
Dimensions and Weight
Physical Dimensions and Weight

Printer unit with basket open and printer stand:
1389 x 984 x 1168 mm (Basket Open)
Weight: 105 kg (including Roll Holder)

Software Included

imagePROGRAF TX-Series Printer Driver, Quick Utility Toolbox, Print Plug-in for Office, Extended Survey Program and Poster Artist Lite other software is available to download from Canon’s web site.

Power and Operating Requirements
Power Supply

Input Power: AC 100-240 V (50-60 Hz)
Power Consumption

Power consumption (using wired LAN): 105 W or less
At sleep mode (using wired LAN): 3.6 W or less
At sleep mode (using all ports): 3.6 W or less
‹EU only - data for ErP Lot 26›
At the power off: 0.3 W or less
Default setting for the time to enter the Sleep mode: 301sec

Operating Environment

15 - 30°C, 10 - 80 % (Condensation free)
Noise Level

Operation : 51dB(A) or less (Plain paper, line drawing, standard mode)
Stand by : 35dB(A) or less
(Measured on ISO7779 standard)
Regulations

Europe: CE, Russia: EAC
Certificates

ENERGY STAR (WW), TUV, CB

Options
Optional Items

Roll Unit: RU-32
Stacker: SS-31
2/3" Roll Holder: RH2-34

Consumables
User Replaceable Items

Print Head: PF-06
Ink Tanks: PFI-110(160ml), PFI-310(330ml), PFI-710(700ml)
Cutter Blade: CT-07
Maintenance Cartridge: MC-30
