Processor:   High-Performance Embedded SOC Processor
Operation System:   Embedded Linux Operation System
DISPLAY PARAMETERS
Display Screen:   3.5-Inch Colorful TFT LCD
Display Resolution:   480 × 320
Operation Method:   Physical Keypad
Operation interface:   LCD Display, Easy Menu
VIDEO PARAMETERS
Camera:   CMOS Low Illumination 1.3 MP HD Colorful Camera
Video Compression Standard:   H.264
Resolution:   1280 x 720
Video frame rate:   PAL: 25 fps, NTSC: 30 fps
AUDIO PARAMETERS
Audio Input:   Built-in Omnidirectional Microphone
Audio Output:   Built-in Loudspeaker
Audio Compression Standard:   G.711 U
Audio Compression Rate:   64 Kbps
Audio Quality:   Noise Suppression and Echo Cancellation
NETWORK PARAMETERS
Ethernet:   10/100/1000 Mbps Self-Adaptive Ethernet
Network Protocol:   TCP/IP, RTSP
ACCESS CONTROL PARAMETERS
Internal Card Reader:   Built-in IC Card Reader
External Card Reader:   Wiegand 26, Wiegand 34, or RS-485 IC Reader
Door Magnetic Detection:   Detects Door Magnetic Status
LIGHT SUPPLEMENT
Light Supplement Mode:   Visible Light Supplement
ALARM PARAMETERS
Alarm Input:   Door Magnetic Alarm, Tampering Alarm
DEVICE INTERFACES
Network Interface:   1 RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface
RS-485:   1 RS-485 Half-Duplex Port
I/O Input:   4
I/O Output:   2
Wiegand:   1 Wiegand Port for Accessing Wiegand IC Card Reader
USB :   1 USB 2.0, Supporting U-Disk
GENERAL
Material:   Aluminum Alloy
Power Supply:   12 VDC
Power Consumption:   ≤15 W
Certification:   FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Working Temperature:   -40° C to +60° C (-40° F to 140° F)
Working Humidity:   10% to 90%
IP Protection Level:   IP65
Dimensions(L × W × H):   357 mm × 124 mm × 55 mm (14.1″ × 4.9″ × 2.2″)
