Wharfedale Pro Delta X10
System Type: Passive
Configuration: Two-way
Frequency Response (+/-3dB): 65-20kHz
Frequency Range (-10 dB): 60-20kHz
Sensitivity (2.83v/1m): 97dB
Calculated Maximum SPL @1m: 128dB
System Rated Impedance: 8Ω
Low Frequency Transducer
Size: 288mm / 10″ Paper
Voice Coil Size: 63.5mm / 2.5″
Rated Impedance: 8Ω
LF Power (re:AES2-2012): 300W
High Frequency Transducer
HF Driver Type: Compression Driver
Voice Coil Size: 44.5mm / 1.75″ Titanium
Exit Size: 25.4mm / 1″
Diaphragm Material: Titanium
Rated Impedance: 8Ω
HF Power (re:AES2-2012): 40W
Nominal Coverage (H x V): 90⁰ x 60⁰
Power
System Continuous Power: 300W
System Programme Power: 600W
System Peak Power: 1200W
Crossover frequency: 2.8kHz
Input Connector: 2 x NL4 (speakON Compatible)
Hardware
Pole Mount: Dual Angle (0⁰ / 10⁰) 35mm Socket
Handles: 2 on Sides
Enclosure
Enclosure Material: 15mm Plywood
Finish: black paint
Grille Material & Finish: 1.5 mm Steel Black or White
Dimensions
Height: 500mm / 19.7″
Width Front: 338mm / 13.3″
Width Rear: 212.4mm / 8.4″
Depth: 330mm / 13.0″
